Customized Fiber Optic Mechanical Connector Manufacturer –GJYXFFCH Aramid FTTH Drop Optical Cable With Self-Supporting Member – FCJ OPTO Detail:

Characteristics

·The outer diameter of the product is small. Compared with the traditional self-supporting outdoor 8-figure cable, the weight is lighter and the installation is more convenient ;
·It has high pressure resistance and tensile resistance, and can stand a certain wind speed；
·Specific V-shaped cable is convenient for stripping and field installation ;
·The outer sheath is made of flame retardant material, which can meet the requirements of flame retardant grade and environmental performance of outdoor optical cable.

Standards
•YDT 1997.1-2014 Access optic-fiber cables for communications – Part 1: Butterfly optical cables, IEC-60332 standard.

Optical Characteristics




G.652

G.657

50/125μm

62.5/125μm

Attenuation
(+20℃)

@850nm

 -

  -

≤3.5dB/km

≤3.5dB/km

@1300nm

  -

  -

≤1.5dB/km

≤1.5dB/km

@1310nm

≤0.34dB/km

≤0.34dB/km

  -

  -

@1550nm

≤0.22dB/km

≤0.22dB/km

 -

  -

Bandwidth
（Class A）

@850

 -

 -

≥500MHZ·km

≥200MHZ·km

@1300

  -

  -

≥1000MHZ·km

≥600MHZ·km

Numerical    aperture

 -

  -

  -

0.200±0.015NA

0.275±0.015NA

Cable Cutoff    Wavelength

 -

≤1260nm

≤1260nm

  -

 -

Technical Parameters

Cabletype

Fiber Count

Cable Diameter
mm

Cable Weight

Kg/km

Tensile Strength

 Long/Short

Term N

Crush Resistance

Long/Short

Term

N/100m

Bending Radius

Static/Dynamic
mm

GJYXFFCH-1~2

1~2 core

2.5*5.65

19.4

500/1000

1000/2200

30D/15D

Storage/Operating Temperature : -40℃ to + 70℃

Product detail pictures:

Customized Fiber Optic Mechanical Connector Manufacturer –GJYXFFCH Aramid FTTH Drop Optical Cable With Self-Supporting Member – FCJ OPTO detail pictures

Customized Fiber Optic Mechanical Connector Manufacturer –GJYXFFCH Aramid FTTH Drop Optical Cable With Self-Supporting Member – FCJ OPTO detail pictures
