Low price for Aerial Cable Self-Supporting - GJFJV Tight Buffer Single Fiber Simplex/Sx 2.0/2.8/3.0mm Fiber Optic Indoor Cable – FCJ OPTO Detail:

Characteristics

Good uniformity of the outer diameter of tight buffer fiber and excellent strippability.
·Good performance of flame-retardant
·Steady performance both in extremely high and low temperature.
·Excellent geometrical dimension of the fiber

Application

·Data Communication
·Making connector
·Installation: Riser,Plenum,inter-layer,pipe & trunking
·Located in where waterproof isn’t strictly required
·Patch cord, Pigtail & Indoor distribution

Standards
·GJFJV cable complies with Standard YD/T1258.2-2003、ICEA-596、GR-409、IEC794 etc; and meets with the requirements of UL approval for OFNR and OI

Cable Code

	SXC-III	SXC-II	SXC-I
Cable Diameter	2.8±0.2mm	2.0±0.2mm	1.6±0.2mm
Cable Weight	6.9kg/km	5.9kg/km	4.0kg/km
Tight Buffer Fiber Diameter	900±50μm	900±50μm	600±50μm

Technical Parameters

Tensile Strength	Long	80N	60	50
Tensile Strength	Short	150N	120	100
Crush Resistance	Long	100N/100mm	100N/100mm	100N/100mm
Crush Resistance	Short	500N/100mm	500N/100mm	500N/100mm
Bending Radius	Dynamic	20XD	20XD	20XD
Bending Radius	Static	10XD	10XD	10XD

Optical Characteristics

		G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm			≤3.0dB/km	≤3.0dB/km
	@1300nm			≤1.0dB/km	≤1.0dB/km
	@1310nm	≤0.36dB/km	–
	@1550nm	≤0.22dB/km	≤0.23dB/km
Bandwidth (Class A）	@850			≥500MHZ·km	≥500MHZ·km
Bandwidth (Class A）	@1300			≥1000MHZ·km	≥600MHZ·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength		≤1260nm	≤1480nm

Environmental Characteristics

Transport Temperature	-20℃～﹢60℃
Storage Temperature	-20℃～﹢60℃
Installation Temperature	-5℃～﹢50℃
Operating Temperature	-20℃～﹢60℃
