Low price for Fc Fiber Adapter - ADSS Single Jacket All Dielectric Self-Supporting Aerial Fiber Optica Cable -FCJ OPTO TECH – FCJ OPTO Detail:

Characteristics

· Continuous electrical erection
· Superior resistance to electric marks with AT sheath
· Light weight, small cable diameter, reduced ice, wind impact and load on tower, support
· Excellent tensile and temperature properties
· Life expectancy up to 30 years

Standards
The ADSS cable follows the IEEE P 1222 technical standard, and meets the IEC 60794-1 standard and DLT 788-2016 standard.

Optical Characteristics

		G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm			≤3.0 dB/km	≤3.0 dB/km
	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.00 dB/km	≤0.00dB/km
	@1550nm	≤0.00 dB/km	≤0.00dB/km
Bandwidth（Class A）	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth（Class A）	@1300nm			≥500 MHz·km	≥500 MHz·km
Numerical aperture				0.200±0.015NA	0.275±0.015NA
Cable Cutoff Wavelength		≤1260nm	≤1480nm

Technical Parameters

Cable Diametermm	Cable Weight kg/km		Recommend maximum working tensionkN	Maximum allowable working tensionkN	breaking tenacitykN	Section area of tensile componentsmm2	modulus of elasticitykN/ mm2	thermal expansion coefficient ×10-6 /k
Cable Diametermm	PE sheath	AT sheath	Recommend maximum working tensionkN	Maximum allowable working tensionkN	breaking tenacitykN	Section area of tensile componentsmm2	modulus of elasticitykN/ mm2	thermal expansion coefficient ×10-6 /k
9.8	121	130	1.5	4	10	4.6	7.6	1.8
10.2	129	138	2.1	5	14	6.9	8.1	1.4
13.1	132	143	2.8	7	19	9.97	9.13	1.2
15.6	189	207	3.8	9	26	14.2	11.2	1.0

Product detail pictures:
