Manufacturer SC-LC Duplex Patch Cord - High Performance
Product Main Parameters
| Parameter | Specification |
|---|---|
| Fiber Type | Single-mode / Multi-mode |
| Fiber Count | 8-96 cores |
| Diameter (mm) | 0.9, 2.0, 3.0 |
| Polish | SM UPC, SM APC, MM UPC, MM APC |
| Insert Loss | ≤0.35dB / ≤0.3dB |
| Return Loss | ≥25dB / ≥50dB |
| Temperature Range | -40~85°C |
Common Product Specifications
| Specification | Detail |
|---|---|
| Connector Type | MPO/MTP 12f/24f, FC/SC/ST/LC/MU/MT-RJ/ESCON/E2000 |
| Exchangeability | ≤0.2dB |
| Repeatability | ≤0.2dB |
Product Manufacturing Process
The manufacturing process of the SC-LC Duplex Patch Cord utilizes advanced techniques to ensure the highest quality of optical transmission. The process starts with the selection of premium optical fibers, followed by precise cutting and polishing to achieve optimal connector end-face geometry. The assembly of the cord involves high-precision components to maintain low insertion loss and high return loss. Automated testing procedures are conducted to ensure conformity with industry standards like Bellcore GR-409-core, IEC 61034, and IEC 754-1. This meticulous manufacturing process guarantees that the products are reliable in performance, suitable for both single-mode and multi-mode applications. As a recognized manufacturer, FCJ OPTO TECH adheres to strict quality controls to deliver consistent and durable products across global markets.
Product Application Scenarios
SC-LC Duplex Patch Cords have widespread applications in modern telecommunications and networking environments. They are crucial in telecommunications networks for seamless data transmission, maintaining backbone connectivity with minimal signal loss. In data centers, these patch cords facilitate high-density connections between servers with their compact design, allowing efficient space utilization. Local Area Networks (LANs) utilize these cords for high-speed and reliable networking solutions in office and campus settings. Additionally, they are employed in broadcast and television sectors for the transmission of high-quality audio and video signals. As a reputable manufacturer, FCJ OPTO TECH provides SC-LC Duplex Patch Cords tailored to meet the specific requirements of these diverse application scenarios.
Product After-Sales Service
We provide comprehensive after-sales support including 24/7 customer service, troubleshooting assistance, and warranty services on all SC-LC Duplex Patch Cords.
Product Transportation
Our SC-LC Duplex Patch Cords are packaged with robust materials ensuring safe transportation. We ship globally with tracking options to provide peace of mind during transit.
Product Advantages
- High data rate and low signal loss performance.
- Secure and stable connections with reliable latching mechanisms.
- Compact design optimizes network scalability.
Product FAQ
- Q: What types of fibers are available? A: As a manufacturer, we offer both single-mode and multi-mode fibers in our SC-LC Duplex Patch Cords, catering to diverse transmission needs.
- Q: What is the temperature range for these cords? A: The cords are designed to operate efficiently within a temperature range of -40°C to 85°C.
- Q: How do I choose between single-mode and multi-mode fibers? A: Single-mode is ideal for long-distance, high-bandwidth applications, while multi-mode suits short-distance, local area networks.
- Q: Can the patch cords handle high data rates? A: Yes, our SC-LC Duplex Patch Cords are engineered to support high data transfer rates, making them suitable for bandwidth-intensive applications.
- Q: What is the typical insertion loss for these connectors? A: Our cords feature low insertion loss, ≤0.35dB for multi-mode and ≤0.3dB for single-mode fibers.
- Q: Are these cords compliant with industry standards? A: Absolutely, they conform to Bellcore GR-409-core, IEC standards, and the WEEE RoHS directive.
- Q: How durable are the connectors? A: The SC and LC connectors feature robust latching mechanisms, ensuring secure and long-lasting connections.
- Q: What lengths are available for these patch cords? A: Our cords are customizable in various lengths to suit your specific networking requirements.
- Q: Can these cords be used in outdoor environments? A: While primarily designed for indoor use, we can provide solutions suitable for outdoor applications upon request.
- Q: How can I ensure I'm getting authentic products? A: Purchase directly from us or through authorized distributors to guarantee authenticity and quality of our manufacturer SC-LC Duplex Patch Cords.
Product Hot Topics
- 1. Innovations in SC-LC Duplex Patch Cords by Manufacturers
Recent advancements in manufacturing technology have led to the development of SC-LC Duplex Patch Cords that are not only efficient but also versatile in handling various network demands. Innovations include improved connector designs that ensure better signal integrity and the use of environmentally friendly materials that comply with international standards. Manufacturers like FCJ OPTO TECH are pioneering these innovations to provide world-class connectivity solutions.
- 2. Importance of Choosing the Right Manufacturer for SC-LC Duplex Patch Cords
The role of a manufacturer in delivering high-quality SC-LC Duplex Patch Cords is crucial for ensuring reliable network operations. Selecting a reputable manufacturer guarantees that the cords meet industry benchmarks for performance and durability, particularly in high-stakes environments like data centers and telecommunication networks. With over 30 years of experience, FCJ OPTO TECH exemplifies the expertise required to produce superior connectivity tools.
