ODM Famous 1X8 PLC Splitter Factories –Fiber Optic Splitter Cable Branching Device Single Mode FC/Upc Interface Telecom PLC Cassette/Rack Splitte – FCJ OPTO Detail:
Features
Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
YD/T 2000.1-2009
RoHS
Product Details
1X N（N≥2）
| PARAMETERS | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 | 1×128 | |
Wavelength (nm) | 1260～1650 | |||||||
Fiber type | G657A 1or custom-defined | |||||||
Pigtail length(m) | 1.0(±0.1) or custom-defined | |||||||
Insertion loss (dB) | ≤3.8 | ≤7.2 | ≤10.3 | ≤13.6 | ≤16.9 | ≤20.4 | ≤23.5 | |
| Loss uniformity(dB) | max | ≤0.8 | ≤1.0 | ≤1.2 | ≤1.5 | ≤1.8 | ≤2.0 | ≤2.0 |
| Return loss (dB) | minimum | 55 | 55 | 55 | 55 | 55 | 55 | 55 |
| PDL (dB) | max | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.4 | ≤0.4 | ≤0.4 |
| Directivity | minimum | ≥55 | ||||||
| Wavelength related loss(dB) | max | ≤0.6 | ≤0.6 | ≤0.6 | ≤0.8 | ≤1.0 | ≤1.0 | ≤1.2 |
| Working temp. ( ℃) | -40～85 | |||||||
| Store temp. ( ℃) | -40～85 | |||||||
bare fiber | 40×4×4 | 50×7×4 | 60×12×4 | 120*26*10 | ||||
ABS package size(LxWxH)mm | 100×80×10 | 120×80×18 | 140×115×18 | 150*130*25 | ||||
Mini package size(Lx W x H)mm | 55×7×4 | 60×12×4 | 80×20×6 | 100×40×6 | 120*50*12 | |||
2X N（N≥2）
| PARAMETERS | 2×2 | 2×4 | 2×8 | 2×16 | 2×32 | 2×64 | 2×128 | |
Wavelength (nm) | 1260～1650 | |||||||
Fiber type | G657A 2 or custom-defined | |||||||
Pigtail length(m) | 1.0(±0.1) or custom-defined | |||||||
Insertion loss (dB) | ≤4.2 | ≤7.5 | ≤10.6 | ≤13.9 | ≤17.2 | ≤20.8 | ≤23.8 | |
| Loss uniformity(dB) | max | ≤0.8 | ≤1.0 | ≤1.2 | ≤1.5 | ≤1.8 | ≤2.0 | ≤2.0 |
| Return loss (dB) | minimum | 55 | 55 | 55 | 55 | 55 | 55 | 55 |
| PDL (dB) | max | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.4 | ≤0.4 | ≤0.4 |
| Directivity | minimum | ≥55 | ||||||
| Wavelength related loss(dB) | max | ≤0.6 | ≤0.6 | ≤0.6 | ≤0.8 | ≤1.0 | ≤1.0 | ≤1.2 |
| Working temp. ( ℃) | -40～85 | |||||||
| Store temp. ( ℃) | -40～85 | |||||||
bare fiber | 50×4×4 | 50×7×4 | 60×12×4 | 120*26*10 | ||||
ABS package size(LxWxH)mm | 100×80×10 | 120×80×18 | 140×115×18 | 150*130*25 | ||||
Mini package size(LxWxH)mm | 60×7×4 | 60×12×4 | 80×20×6 | 100×40×6 | 120*50*12 | |||
Remark: these datas not include connector loss,Each connector will add 0.25dB loss, each adapter will add extra 0.2dB loss
Application
● FTTH (Fiber to the home)
● Access/PON distribution
● CATV NETWORK
● High reliability/Monitoring/other Network systems
Rack type PLC type in Network systems Best Alternative for FTTx Solution: Being installed in an outside plant enclosure, PON splitter is used to distribute or combine optical signals, which gives carriers the ability to split optical signals to multiple homes or businesses.
